The Air Vantage® 566 Hydraulic is the first of its kind—a true 600-amp welder that integrates four essential jobsite systems into one rugged, high-output unit. Combining a 600A multi-process welder, 20,000-watt continuous generator, 60 CFM rotary screw air compressor, and a 10 GPM hydraulic pump, this machine is engineered for the most demanding fieldwork.

Powered by a 65 HP Deutz® TD2.9L4 Tier 4 Final diesel engine, the 566 delivers performance that meets today’s toughest emissions standards, making it ideal for heavy equipment service, railroads, pipelines, and utility infrastructure work.

💥 All-in-One Powerhouse

• 600A Multi-Process Welder: Supports Stick, MIG, TIG, and Flux-Cored processes with consistent arc quality and full power at high duty cycles.

• 20,000W Continuous AC Power: Run single-phase and three-phase tools, welders, and sensitive electronics simultaneously—thanks to clean power with consistent voltage regulation.

• 60 CFM VMAC® Air Compressor: Delivers instant air at 100 PSI (max 150 PSI) to run 1" impact guns and other large pneumatic tools with ease.

• 10 GPM Hydraulic Pump: Supports external tools and systems with up to 3,000 PSI—perfect for boom lifts, jacks, and other mobile hydraulic gear.

⚙️ Quick Specs

• Duty Cycle: 60% @ 600A | 100% @ 525A

• DC Range: 30–600A (CC/CV) | 20–350A (GTAW)

• AC Power Output: 12,000W (1-Ph) | 20,000W (3-Ph)

• Dimensions: 69" L x 32.9" W x 42" H

• Weight: 1,800 lbs

🔧 Engine & Component Specs

• Engine: Deutz TD2.9L4 Diesel | 65 HP @ 1800 RPM

• Fuel Capacity: 25 gal | Oil: 2.25 gal

• Start: 12V Battery + Auto Glow Plugs

• Air Compressor: VMAC S700162 | 60 CFM @ 100 PSI | 1.1 gal tank

• Hydraulic Pump: Casappa PHP20 | 10 GPM @ 3000 PSI | Electro-Clutch

From power generation and compressed air to hydraulics and high-amperage welding, the Air Vantage 566 does it all—one machine, zero compromise.
